24. Механизм блока управления (5)

Вернуться к выбору схем

Выбор схемы:

24. Механизм блока управления (5)

Как искать запчасти?

30-4-7

30-4-8

30-4-3

30-4

30-4

30-5

30-4-2

30-4-1

30-4-4

30-4-6

30-4-5

30-6

30

30

30

30

30

30

30

30

30

30

30

30

51-3-10

51-4-10

51-2-10

51-2-9

51-3-9

51-4-9

51-4-11

51-3-11

51-4

51-4-7

51-3-7

51-2-7

51-3

51-4-1

51-2

51-3-1

51-2-1

51-

51-4-12

51-3-12

51-2-12

51-3-6

51-4-6

51-2-6

51-4-5

51-3-5

51-2-5

51-2-11

51-3-7-3

51-2-7-3

51-4-7-3

51-2-7-2

51-4-7-2

51-3-7-2

51-3-3

51-2-3

51-4-3

51-3-7-1

51-2-7-1

51-4-7-1

51-4-4

51-3-4

51-2-4

51-3-8

51-2-8

51-4-8

51-2-2

51-3-2

51-4-2

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

51

56-2

56-2

56-1

56-1

56-1-1

56-1-1

56-1-4

56-1-5

56-1-5

56-1-2

56-1-2

56-1-3

56-1-3

56

56

57

57

58

58

59

59

100%

№

Артикул Артикул и наименование

Наименование

S50447001 power supply switch assy_ d

S50445000 power supply cord b

S38133000 power supply cord

J02657001 push switch_ 3p #17

224514001 insulation plate

218859001 binder m150

S40623000 emi core tr-40-27

S50448000 power supply cord, e

S50500000 ac cord, f

028060246 washer_ spring 2-6

S54027001 transformer assy, b110; conv.

S50638101 transformer assy_ c380 ;conv.

S54027001 transformer assy, b110; conv.

028060246 washer_ spring 2-6

S10820006 label, 380v ac

0A4400606 screw, pan (s/p washer) m4x6

S54028001 base plate, trans.

S50474000 handle

S41964000 bushing

062500602 screw 5x6

S23618001 screw 6x10 0506b

S50639100 transformer, c380; conv.

S38128000 conversion transformer, c

S50485100 harness, tr-in

S50486100 harness, tr-out

018060831 bolt_ socket m6x8

025060236 washer 6

S50640101 transformer assy, c400; conv.

S54027001 transformer assy, b110; conv.

028060246 washer_ spring 2-6

S10820008 voltage label

0A4400606 screw, pan (s/p washer) m4x6

S54028001 base plate, trans.

S50474000 handle

S41964000 bushing

062500602 screw 5x6

S23618001 screw 6x10 0506b

S50641100 transformer, c400; conv.

S38128000 conversion transformer, c

S50485100 harness, tr-in

S50486100 harness, tr-out

018060831 bolt_ socket m6x8

025060236 washer 6

S50642101 transrormer assy, c415; conv.

S54027001 transformer assy, b110; conv.

028060246 washer_ spring 2-6

S10820007 voltage label ac

0A4400606 screw, pan (s/p washer) m4x6

S54028001 base plate, trans.

S50474000 handle

S41964000 bushing

062500602 screw 5x6

S23618001 screw 6x10 0506b

S50643100 transformer, c415; conv.

S38128000 conversion transformer, c

S50485100 harness, tr-in

S50486100 harness, tr-out

018060831 bolt_ socket m6x8

025060236 washer 6

S50498001 noise filter assy_ eh

S40616001 noise filter assy, eh

S40617000 noise filter assy, emc

S40618000 capacitor, ceramic: eckdna102mb

S40619000 capacitor polyester: 250b474

414900001 header 5219-03a

S35598000 coil, sc0520j

S50499000 noise filter harness

S40620000 circuit board set plate

0A4400605 screw_ pan (s_p washer) m4x6

0A4400605 screw_ pan (s_p washer) m4x6
