Главная Каталог запчастей Запчасти для промышленных швейных машин Brother SL-1110/S-7550A BROTHER 09. Feed mechanism

09. Feed mechanism

Вернуться к выбору схем

Выбор схемы:

09. Feed mechanism

Как искать запчасти?

1

2

3

4

5

6

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

61

62

63

64

65

66

67

68

69

70

71

72

73

74

75

76

77

78

79

80

81

82

83

84

85

86

87

88

89

90

100%

№

Артикул Артикул и наименование

Наименование

156949021 level feed connecting rod

156948021 Держатель (Арт. 156948021)

108960002 screw, flat sm3.57

S05898121 level feed regulator assy

156950220 level feed regulator

156951021 Штифт звена механизма закрепки (Арт. 156951021)

014680632 set screw socket sm4.37-40x6

156952021 feed rocker link assy

156954021 feed rocker arm link assy

156956021 link shaft

144458001 set screw, sm3.57-40x4.5

156957120 feed rocker arm

062711412 screw pan sm4.76-32x14

156958021 feed rock arm shaft

014680632 set screw socket sm4.37-40x6

S40027021 f-regulator connect rod assy

S04228001 spring hook

048060342 retaining ring e6

120990001 set screw, (cp) sm4.37-40x8

156967121 feed regulator shaft, l

118734021 feed regulator shaft

118735021 washer

014760632 set screw socket sm5.95-28x6

156969121 Регулятор подачи (Арт. 156969121)

156970021 feed regulator shaft

S02556021 washer

048070342 retaining ring e7

014761030 set screw socket sm5.95-28x10

151308121 stud, 12.5

S47264001 set screw, socket (cp) sm4.37

S40029120 lever

062711412 screw pan sm4.76-32x14

151308121 stud, 12.5

S47264001 set screw, socket (cp) sm4.37

SA8156001 reverse stitching lever assy

S02561001 spring hook pin

062711412 screw pan sm4.76-32x14

147505101 shaft, r-lever

147504221 spacer

025100132 washer plains 10

048080342 retaining ring e8

104564001 o ring

062670712 screw pan sm3.57-40x7

S02562021 spring hook

S02563001 spring, extension

145502021 positioning pin

100328001 notch spring

S02568121 feed rocker shaft

S31014020 bush 19.3

156243021 thrust ring

048150142 retaining ring external c15

SA8157001 set screw collar assy

014770632 set screw socket sm6.35-40x6

156244020 feed rocker bracket arm

062681212 screw pan sm4.37-40x12

S02569121 feed bar assy

S02573020 washer

S25349021 feed bar stud

158722021 washer plain 4.2

120990001 set screw, (cp) sm4.37-40x8

62

100080004 Под заказ Винт, SM3.18-44X6.5 Тип.S 7220C-403/PFL (Арт.100080004)

S02574121 feed lifting rocker shaft

S31014020 bush 19.3

156243021 thrust ring

048150142 retaining ring external c15

180322021 feed lifting arm assy

062681412 screw pan sm4.37-40x14

SA8157001 set screw collar assy

014770632 set screw socket sm6.35-40x6

S02575020 Рукоятка вала (Арт. S02575020)

062711212 screw pan sm4.76-32x12

147509021 Винт с шейкой (Арт. 147509021)

104689002 nut 7.14

118758021 connecting rod, v-feeding

159690021 feed cam stopper

062670412 screw pan sm3.57-40x4

S21514221 screw sm4.76

108549001 o ring

014761030 set screw socket sm5.95-28x10

014760632 set screw socket sm5.95-28x6

047200642 pin spring rollaw2

SA8184001 level feed eccentric wheel w/s (for -3 (for turkey) & -5 )

S03818101 extension spring, h (for -3 (for turkey) & -5 )

SA8185001 f-lift eccentric wheel w/screw (for -3 (for turkey) & -5 )

S31018021 stitch length dial assy 5 (for -3 (for turkey) & -5 )

S01753021 stopper (for -3)

062680812 screw pan sm4.37-40x8 (for -3)

110735022 washer (for -3)
