9. Bobbin Thread Trimmer Components

Вернуться к выбору схем

Выбор схемы:

9. Bobbin Thread Trimmer Components

Как искать запчасти?

1

2

3

4

5

6

7

8

9

10

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

100%

№

Артикул Артикул и наименование

Наименование

95-09-001 Needle Plate Asm.

95-09-002 Needle Plate

95-09-003 Screw (9/64-40 L=4.5)

95-09-004 Throat Plate Base Asm.

95-09-005 Bobbin Thread Trimmer Blade Asm.

95-09-006 Screw

95-09-007 Counter Knife

95-09-008 Screw (1/8-44 L=3)

95-09-009 Bobbin Thread Trimmer Lever

95-09-010 Screw

95-09-011 Washer

95-09-012 Bobbin Thread Puller

95-09-013 Screw (9/64-40 L=4.0)

95-09-014 Screw (9/64-40 L=7.8)

95-09-015 Hook Thread Presser Stopper

95-09-016 Presser Plate

95-09-017 Screw (11/64-40 L=7.8)

95-09-018 Bobbin Picker Presser Plate

95-09-019 Hinge Screw

95-09-020 Bobbin Picker Bracket

95-09-021 Screw (9/64-40 L=6)

95-09-022 Bobbin Picker Bracket Shaft

95-09-023 Bobbin Screw

24

B2401-771-0A0 (assmb.) Под заказ Игольная пластина в сборе (с мех-мом обрезки нити) Тип.JY-K783 (Juki LBH-780 series) (Арт.B2401-771-0A0 (assmb.))

95-09-025 Screw (11/64-40 L=6)

95-09-026 Presser Plate Adjusting Spring

95-09-027 Presser Plate Mounting Base

95-09-028 Bobbin Thread Trimmer Link

95-09-029 Nut (3/16-28)

95-09-030 Presser Plate Adjusting Screw

95-09-031 Hinge Screw

95-09-032 Hinge Screw

95-09-033 Bobbin Thread Guide

95-09-034 Screw (9/64-40 L=5)

95-09-035 Washer

95-09-036 Hinge Screw

95-09-037 Bobbin Thread Trimmer Driving

95-09-038 Nut (15/64-28)

95-09-039 Connecting Link

95-09-040 Stop Screw

95-09-041 Nut (6/32-28)

95-09-042 Hing Stud

95-09-043 Screw (15/64-28 L=7)

95-09-044 Bobbin Thread Trimmer Driving

95-09-045 Hinge Screw

95-09-046 Ball Screw

95-09-047 Nut (15/64-28)
