16. Lubrication mechanism components

Вернуться к выбору схем

Выбор схемы:

16. Lubrication mechanism components

Как искать запчасти?

1

2

3

3

4

5

6

7

8

9

10

10

11

11

12

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

45

46

47

48

49

50

51

52

52

53

53

54,55

54

55

56

56

57

57

58

58

59

60

61

62

63

64

65

66

67

68

69

70

71

72

73

74

75

75

76

76

77

77

78

78

79

80

81

82

100%

№

Артикул Артикул и наименование

Наименование

40009374 oil felt holder

B3549771000 oil return felt (a)

B3568771000 oil return tube

B3571771000 pipe holder

SS7110710SP screw 11/64-40 l=7

SS7110910TP screw 11/64-40 l= 8.5

40009369 pipe guide (a)

BP600000000 vinyl pipe

BP500000000 vinyl pipe

BP300000000 vinyl pipe

SQ1110402MZ connecting screw

B3534012000 gasket

B3534155000 plunger

B1214038000 plunger spring

40009361 thrust plate

SS4150715SP screw 15/64-28 l=7

40009373 oil felt guide

SS7110710SP screw 11/64-40 l=7

B3560771000 oil felt

B11357710A0 oil pan asm.

SS4110515SP screw 11/64-40 l=5

B3561771000 oil unwoven cloth

B1148771000 oil felt

B1147771000 oil felt

B3563771000A oil shield

SS4110515SP screw 11/64-40 l=5

B1124771000 cushion

B1154781000 belt guard

B115478100A belt guard

SS4110815SP screw 11/64-40 l=8

40009001 plate spring

40009003 set nut

B1156781000 rubber bushing

BP800000000 vinyl tube, white d=8

CQ303000000 oil wick

40009360 oil pump base

SS4110815SP screw 11/64-40 l=8

B3570771000 filter

B3546771000 oil felt

40009375 spring

40009366 filter screen

40009379 bushing holder

SS7090910SP screw 9/64-40 l= 8.5

NS6090310SP nut 9/64-40

NS6150310SP nut 15/64-28

40008994 driving pin base

B11517810A0A machine base asm.

B11517810AAA machine base asm.

B1151781000A machine base

B115178100A head base

40008996 guide pin

40009035 rubber cushion

SS7111120SP screw 11/64-40 l=10.5

B1122761000 hinge holder

26109207 hinge holder

B1120761000 pin

SM6062002TP screw m6 l=20

WP0621016SD washer 6.2x13x1

SS6741010SP screw 3/8-28 l=10

B8219125000 oil drain cap gasket

40009244 starting lever pressure spring

SM9082003CP screw m8 l=20

NS6150310SP nut 15/64-28

40009235 stop screw asm.

NM6080721SE nut m8

SS7151210SP screw 15/64-28 l=12

40009231 starting link shaft

SS9150860SP screw 15/64-28 l=8

SS8150710SP screw 15/64-28 l=7

B2655781000 starting lever

RE0600000K0 e-ring 6

B71607810A0 shifter driving pin

SS7112420SP screw 11/64-40 l=24

B1133761000 machine base felt pad

B1153771000 machine base screw stud

WP0612056SD washer 6.1x18.5x2

B8213012000 bed hinge connection

BP300000000 vinyl pipe

BP500000000 vinyl pipe

BP800000000 vinyl tube, white d=8

BP400000000 vinyl tube, white d=4
