Главная Каталог запчастей Запчасти для промышленных швейных машин Aurora A-20U43 AURORA 1. Корпус машины

1. Корпус машины

Вернуться к выбору схем

Выбор схемы:

1. Корпус машины

Как искать запчасти?

1

2

3

4

5

6

7

8

9

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

34

35

36

36

37

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

61

62

63

64

65

66

67

68

69

70

71

72

73

74

75

76

77

78

79

80

81

100%

№

Артикул Артикул и наименование

Наименование

U43T1-0 housing

U43T1-1-3 model plate

U43T1-1-7 model plate rivet

U43T1-1-8 model-plate

U43T1-2-1 face plate

U43T1-2-3 thread guide nut

U43T1-2-2 thread guide screw

U43T1-2-3 thread guide nut

U43T1-3 face plate screw

U43T1-4 linear lock eccentric screw

U43T1-5 linear lock eccentric

U43T1-6-1 thrust plate

U43T1-6-2 thrust plate spring

U43T1-6-3 needle plate

U43T1-7 needle plate

U43T1-8 needle plate screw

U43T1-9-1 inner cover plate

U43T1-9-2 cover plate spring

U43T1-9-3 cover plate spring screw

U43T1-10 thread take up lever shield

U43T1-11 shield screw

U43T1-12 washer

U43T1-13 rotating hook shield

U43T1-14 rotating hook shield screw

U43T1-15 thread-releasing lever

U43T1-16 thread-releasing lever spring

U43T1-17 thread-releasing lever screw

U43T1-18 lower thread-running rack

U43T1-19 double thread-running rack

U43T1-19a thread-running rack

U43T1-20 thread-running rack screw

U43T1-21 thread-releasing pin

U43T1-22 thread-hold fixing screw

U43T1-23-1 thread tension regulator bushing

U43T1-23-2 fixing screw

U43T1-23-3 thread take-up spring

U43T1-23-4 thread tension stud

U43T1-23-5 thread tension disc

U43T1-23-6 thread tension-releasing disc

U43T1-23-7 thread tension spring

U43T1-23-8 thumb nut revolution stopper

U43T1-23-9 thumb nut

U43T1-24 upper cover

U43T1-25 upper cover back screw

U43T1-26 3-eyelet hole thread guide

U43T1-27 3-eyelet hole thread guide screw

U43T1-28 rubber plug (big)

U43T1-29 rubber plug (medium)

U43T1-30 rubber plug (small)

U43T1-31 upper cover set screw

U43T1-32 fastening screw

U43T1-33-0 upper thread-guide component

U43T1-33-1 thread-guide

U43T1-33-2 thread-tension disc

U43T1-33-3 upper thread-tension disc

U43T1-33-4 upper thread-tension spring

U43T1-34 back cover

U43T1-35 back cover screw

U43T1-37 locating block set screw

U43T1-37-1 locating block

U43T1-38 volume-adjusting sprindle

U43T1-39 washer

U43T1-40 pressing plate screw

U43T1-41 volume-adjusting plate

U43T1-42 extension spring pin

U43T1-43 extension spring

U43T1-44 crank screw

U43T1-45 thread-winding swaying handle

U43T1-46 swaying handle presser spring

U43T1-48 thread-winding small wheel

U43T1-49 thread-winding rubber wheel

U43T1-50 thread-winding axis spring

U43T1-51 thread-winding crank

U43T1-52 thrum nut

U43T1-53 thrum nut revolution stopper

U43T1-54 thread-tension spring

U43T1-55 thread-tension cover base

U43T1-56 thread-tension cover base

U43T1-57 upper cover
