2. Механизм нитепритягивателя и игловодителя

Вернуться к выбору схем

Выбор схемы:

2. Механизм нитепритягивателя и игловодителя

Как искать запчасти?

1

2

3

4

5

6

7

8

9

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

31

32

33

33

34

35

35

36

37

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

100%

№

Артикул Артикул и наименование

Наименование

U43T2-2 pin screw (swaying rack of needle staff)

U43T2-3 swaying rack of needle bar

U43T2-4 eccentric pin screw of needle bar

U43T2-5 locating plate of needle bar

U43T2-6 scrwe of locating plate

U43T2-7 pin of swaying rack (needle bar)

U43T2-8 needle bar

U43T2-9 thread-guide of needle bar

U43T2-10 needle

U43T2-11 locking screw of needle

U43T2-12 pin-screw of connecting shaft

U43T2-13 pin-washer of connecting shaft

U43T2-14 connecting shaft

U43T2-15 pin of connecting shaft

U43T2-16 pin-locking scrwr of cnnecting shaft

U43T2-17 guide of small connecting staff

U43T2-18 scrwe of guide

U43T2-19 guide washer

U43T2-20-0 thrad take-up lever component

U43T2-20-1 left-spiral screw

U43T2-20-2 small connecting staff

U43T2-20-3 crank of needle bar

U43T2-20-4 thread take-up lever component

U43T2-20-5 stitch-swaying staff

U43T2-20-6 pin of swaying staff

U43T2-20-7 pin screw of swaying staff

U43T2-20-8 scrw of crank

U43T2-20-9 crank

U43T2-20-10 crank fastening screw

U43T2-20-11 thread take-up lever

U43T2-21 fasterning screw of front sleeve

U43T2-22 front sleeve of upper shaft

U43T2-23 screw of spiral gear

U43T2-24 spiral gear of upper shaft

U43T2-25 screw of arc-cone gear

U43T2-26 arc-cone gear (upper shaft)

U43T2-27 screw of feed cam

U43T2-28 feed cam

U43T2-29 upper shaft

U43T2-30 back sleeve of upper shaft

U43T2-31 fasterning scrwe of back sleeve

U43T2-32 sleeve of balance wheel

U43T2-33 sleeve wheel

U43T2-34 balance wheel

U43T2-35 clutch washer

U43T2-36 clutch screw

U43T2-37 small clutch screw

U43T2-39 swaying rack of needle bar

U43T2-40 needle bar for double needle

U43T2-41 fasterning screw of double needle clamper

U43T2-42 double needle clamper (2.5mm)

U43T2-43 double needle clamper (3.5mm)

U43T2-44 double needle clamper (4.5mm)

U43T2-45 fasterning screw
