Главная Каталог запчастей Запчасти для промышленных швейных машин Aurora A-611 AURORA 6. Hand Lifter Components

6. Hand Lifter Components

Вернуться к выбору схем

Выбор схемы:

6. Hand Lifter Components

Как искать запчасти?

1

2

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

32

33

34

35

36

37

38

39

40

41

42-1

42

43

44

45

46

47

48-1

48

49

50

51

51

52

53

53

54

55

56

56

56

56

57

58

59

60

61

61

62

100%

№

Артикул Артикул и наименование

Наименование

1300-06-01 Presser Lifting Shaft

11-80150710-01 Screw Sm15/64x28 L=7

1300-06-03 Upper Feed Driving Shaftbushing(left)

1300-06-04 Upper Feed Driving Shaftbushing(right)

1300-06-10 Upper Feed Driving Control Crank

11-60121420-01 Screw Sm3/16x28 L=15

1300-06-12 Support Shaft

1300-06-13 Climb Device Adjusting Shaft

25-10000000-08 Retaining Ring

1300-06-15 Crank Shaft

1300-06-16-6 Set Screw

1300-06-17 Climb Device Adjusting Shaft Bushing(rear)

1302-06-18 Climb Device Adjusting Shaft

1300-06-19 Return Spring For Climb Device Adjusting Shaft

02-013A-3710 Thrust Collar

11-80160510-01 Screw Sm1/4x40 L=5

120-06-28 Set Screw

1300-06-23 Upper Feed Driving Rod

24-06000000-09 E-ring

1300-06-25 Upper Feed Connecting Link Pin

1300-06-26 Upper Feed Connecting Link

1300-06-27 Presser Bar Bracket Connecting Link

1300-06-28 Pin For Presser Bar Bracket Connecting Link

1300-06-29 Set Screw

1300-06-30 Upper Feed Lever Rock Crank

13-60153320-01 Nut

11-80151412-01 Screw Sm15/64x28 L=10

1300-06-34 Stopper Pin

120-06-01 Lifting Presser Adjusting Screw

13-60183620-01 Lifting Presser Adjusting Nut

1300-06-37 Frame For Upper Feed Pressure Adjusting Screw

SG11-60111120-01 Screw Sm11/64x40 L=11

15-094G-640L Lifting Presser Spring

1300-06-40 Upper Feed Pressure Adjusting Spring Bar

1300-06-41 Upper Feed Lever Connecting Pin

1300-06-42 Presser Rod

1301-06-42 Presser Rod

1300-06-43 Ascension Presser Foot Guide Pin

11-70090820-01 Screw Sm9/64x40 L=8

120-06-46 Space For Presser Rod Plate

11-60111220-01 Screw Sm11/64x40 L=12

15-032C-3400 Lifting Presser Rod Plate

48

1300-06-48 Под заказ Прижимная лапка внешняя Тип.A-611D, A-3500 (Арт.1300-06-48)

48-1

122-06-45 Под заказ Лапка внешняя Aurora A-611, A-611D, A-0818

1300-06-05 Upper Feed Driving Crank

11-60151460-01 Screw Sm15/64x28 L=14

1300-06-07 Connecting Pin For Upper Feed Driving Crank

1300-06-08 Upper Feed Driving Connecting Link

11-80110512-01 Screw Sm11/64x40 L=5

1300-06-16-7 Set Screw

1300-06-50 Climb Device Adjusting Shaft Bushing(front)

21-10135180-01 Washer

1300-06-52 Climb Device Eccentric Cam(long)

120-02-65 Spring

1300-06-34 Stopper Pin

1300-06-55 Climb Device Dial Asm.(arm )

11-80151550-01 Screw Sm15/64x28 L=10

15-061A-640L Climb Device Eccentric Cam(short)

1300-06-58 Climb Device Dial Asm.(top Cover)

1300-06-59 Set Screw

21-04608080-01 Washer

1300-06-32 Upper Feed Lever Rock Crank Shaft
