7. Presser Lifting Mechanism

Вернуться к выбору схем

Выбор схемы:

7. Presser Lifting Mechanism

Как искать запчасти?

1

2

3

4

5

6

7

8

9

10

11

12

13-1

13-2

13

13

14

15

16

17

18

19

20

21

22

23

24

25

26-1

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

100%

№

Артикул Артикул и наименование

Наименование

11-00110520-01 Screw Sm11/64x40 L=5

1300-07-10 Spring Of Knee Lifter Lever

120-05-16 Spring Of Pin

120-05-14 Hinge For Knee Lifting Link Screw Sm15/64x28 L=7

1300-07-13-01 Knee Lifter Lever(right)

1300-07-13-01 Knee Lifter Lever(right)

1300-07-13-02 Knee Lifter Lever Pin

1300-07-02 Upp Thread Guide

1300-07-03 Presser Bar Bushing

11-80150810-01 Screw Sm15/64x28 L=8

1300-07-05 Pressure Regulating Thumb Screw

1300-07-06 Nut For Pressure Adjusting Screw

120-05-21 Presser Bar Spping

101-04-32 Hinge Screw For Presser Bar Connecting Stick(long)

1300-07-09 Knee Lifter Rod

1300-07-14 Presser Bar Lifting Cam

1300-07-15 Stopper Pin For Presser Lifter Cam

11-80150510-01 Screw Sm15/64x28 L=5

1300-07-17 Torsion Spring For Presser Bar Lifter Shaft

1300-07-18 Presser Bar Lifter Shaft

31-04018000-09 O-ring For Presser Bar Lifter Shaft

1300-07-20 Hand Lifter

1300-07-21 Knee Lifting Bar Stick

11-60110721-01 Presser Bar Lifting Link(left)screw Sm11/64x40 L=7

1300-07-23B Presser Bar Lifting Link(left)

120-05-06 Tension Releasing

1300-07-25 Shaft For Tension Pelease Plate Asm.

26

1300-07-26 Под заказ Прижимная лапка внутренняя Тип.A-611D (Арт.1300-07-26)

26-1

122-05-27 В наличии мало (на удаленном складе) Лапка внутренняя Aurora A-611, A-611D, A-0818

11-60091120-01 Press Foot Screw Sm9/64x40 L=11

1300-07-28 Presser Bar Bushing

1300-07-29 Presser Bar

11-80110612-01 Screw Sm11/64x40 L=6

21-04210080-02 Washer

05-019M-3400 Presser Bar Shield

40-003A-2700 Adjust The Column

120-05-08 Hinge Screw For Presser Bar Connecting Stick(short)

1300-07-35 Sub Pressure Adjusting Screw

1300-07-36 Sub Pressure Adjusting Spring

1300-07-23 Presser Bar Lifting Link(left)

21-06106100-01 Washer

11-40090525-01 Screw Sm9/64x40 L=5

1300-07-40 Tension Release Cable Holder(upper)

40-033A-64L7 Tension Release Cable Asm.

1300-07-42 Tension Release Plate Asm.

24-08000000-09 Snap Ring

1300-07-44 Spring For Tension Release Plate Asm.

24-05000000-08 Snap Ring

1300-07-46 Bracket For Tension Release Cable Holder(lower)

21-04508080-01 Washer

12-60401022-01 Screw M4 L=10

1300-07-49 Tension Release Cable Holder(lower)

14-60504020-02 Nut M5 H=4

40-004C-2700 Nut M5 H=4

12-40401025-01 Screw M4 L=10

24-06000000-08 Ring

11-80160612-01 Screw Sm1/4x40 L=6

1300-07-25B Presser Bar Lifting Link Pin
