B. Needle Bar and thread take-up mechanism

Вернуться к выбору схем

Выбор схемы:

B. Needle Bar and thread take-up mechanism

Как искать запчасти?

1

2

2

2

3

4

5

6

6

7

8

8

9

9

10

11

11

12

12

12

13

13

14

14

15

15

16

17

18

18

19

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

44

45

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

61

62

100%

№

Артикул Артикул и наименование

Наименование

SA7209201 Upper Shaft Assy

S23651001 Set Screw Socket (FT) (M6x6)

S25235001 Screw (M8)

S25236001 Set Screw Socket (FT) (M6x10)

SA1120001 Bobbin Winder Driving Wheel

S23651001 Set Screw Socket (FT) (M6x6)

110367001 Washer, Plain Special 8

SA9751001 Needle Bar Connecting Rod Unit (S)

SA7627001 Needle Bar Crank (S)

SA8061001 Set Screw Socket (CP) (M3x4) Seal

SA2422001 Screw (SM3,57L)

012400436 Set Screw Socket (FT)(M4x4)

SA2161001 Washer

048060342 Retaining Ring E6

15

140004001 Под заказ Винт, SM3.57-40X7 Тип.S 7220C-403/PFL (Арт.140004001)

SA7239101 Stopper Pin

012500536 Set Screw Socket (FT) (M5x5)

012061036 Set Screw Socket (FT) (M6x10)

19

102630001 В наличии (на удаленном складе) Блок скольжения Тип.430 кл (Арт.102630001)

*P.53-55 Needle Bar

SA2194201 Needle Bar Bush U

SA1139101 Needle Bar Bush D (5)

012500536 Set Screw Socket (FT) (M5x5)

062500616 Screw Pan (M5x6)

140553102 Set Screw (SM3,18)

S23651001 Set Screw Socket (FT) (M6x6)

SA2250101 Timing Pulley, U

S38712001 Flange

SA2404001 Screw, Pan (S Washer) (M4x35)

151594001 Needle Bar Thread Guide

32

151267001 Под заказ Винт, плоский SM4.37-40X8 тип S 7220C-403/PFL (Арт. 151267001)

180018151 Slide Plate Assy

114561001 Spring, Plate

122771051 Screw (SM2,38)

SA1143101 Lower Shaft Assy

SA1144001 Lower Shaft

048120142 Retaining Ring External C12

S25401100 Oil Seal

SA1317101 Oil Seal

SA1167001 Lower Shaft Gear

S23651001 Set Screw Socket (FT)(M6x6)

SA2251001 Timing Pulley, D

S23651001 Set Screw Socket (FT) (M6x6)

SA2378001 Spacer (4,8)

SA1150101 Bearing Bush Assy

S23651001 Set Screw Socket (FT) (M6x6)

48

Под заказ Приводной ремень (арт. SA2252101)

S23651001 Set Screw Socket (FT) (M6x6)

SA2254101 Lower Shaft Bush

SA8058301 Tension Pulley Unit

SA9763001 Tension Pulley Assy

S50165001 Collar

018102536 Bolt Socket (M10x25)

021100302 Nut (3M10)

SA8059101 Pulley Base

SA8060201 Tension Pulley Plate

018061036 Bolt Socket (M6x10)

025060136 Washer Plain S6

018061236 Bolt Socket (M6x12)

*P.53-64 Needle Plate

*P.49, 53-55 Needle
