H1. Смазка

Вернуться к выбору схем

Выбор схемы:

H1. Смазка

Как искать запчасти?

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

21

22

23

24

24

25

26

27

28

29

30

31

32

33

34

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

76

77

78

79

100%

№

Артикул Артикул и наименование

Наименование

SA1292001 Wick Holder Assy

SA1295001 Cord Holder (T2)

062500816 Screw Pan (M5x8)

SA9689001 Oil Tube Assy

S25382001 Oil Feeding Pipe

SA9670001 Oil Tank Set (3)

062500816 Screw Pan (M5x8)

062500616 Screw Pan (M5x6)

145737001 Felt Support

081004070 O Ring (P4)

111863001 Needle Bar Cork (5)

144875001 Plunger

SA7636201 Pump Cap Screw Assy

S25380601 Cap Screw Pump

S52764001 Spring Compression

104821001 Rubber Cap (10,5)

SA9792001 Adjusting Screw

081004870 O Ring (S4)

140327001 Rubber Cap (6,3)

S25382001 Oil Feeding Pipe

SA9735001 Oil Tank Middle Unit

S25382001 Oil Feeding Pipe

S5181501 Oil Feeding Pipe (8,6)

SA1303101 Screw (M8)

081008070 O Ring (P8)

SA8989001 Oil Feeding Pipe

081006670 O Ring (PW6)

SA8987001 Filter

SA8991001 Rubber Cap (35-12)

SA9696001 Vinyl Tube

SA9793001 Vinyl Tube (L=122)

SA9794001 Vinyl Tube (L=110)

0A4501206 Screw Pan (S/P Washer) (M5x12)

SA1306001 Sub Tank Assy

SA1307001 Sub Tank

S51815001 Oil Feeding Pipe (8,6)

081022870 O Ring (S22)

SA9795101 Float Assy

S47509001 Oil Gauge Window

SA2779002 Oil Gauge Window

SA9828101 Oil Gauge Window

SA9691001 Bed Bottom Cover Unit

S51272100 Oil Window, B-Cover

081015870 O Ring (S15)

SA1313101 Window Cover

062500616 Screw Pan (M5x6)

SA1303101 Screw (M8)

081008070 O Ring (P8)

SA9639001 Bottom Cover Fel T

SA1315301 Bottom Cover Fel T

062400616 Screw Pan (M4x6)

025040332 Washer Plain (L4)

SA1314001 Bottom Cover Packing

062501216 Screw Pan (M5x12)

SA9694001 Cord Holder Plate

062500616 Screw Pan (M5x6)

081029870 O Ring (S29)

SA9753101 Oil Feeding Pocket Unit

SA9697001 Tube Holder

012060536 Screw Pan (M5x6)

SA9917001 Oil Feeding Pocket Cover
