4. Needle Driving Shaft Components

Вернуться к выбору схем

Выбор схемы:

4. Needle Driving Shaft Components

Как искать запчасти?

1

2

3

4

5

6

7

8

9

9

11

11

12

14

15

16

17

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

52

53

54

54

55

55

56

56

56

56

57

57

58

58

59

60

61

62

63

64

65

66

67

67

68

100%

№

Артикул Артикул и наименование

Наименование

131-10556 Feed Rocked Crank Asm.

1313-10507 Needle Driving Brach Crank

SM-6061402-TP Screw (M6 L=14)

131-10606 Needle Driving Shaft

131-10101 Bushing, Rear

132-09853 Needle Driving Arm Asm.

132-09804 Needle Driving Arm

SM-6061402-TP Screw (M6 L=14)

132-09101 Needle Driving Arm Pin A

132-09309 Needle Driving Arm Pin C

132-09408 Needle Driving Pin A

132-09606 Needle Driving Pin C

131-10002 Bushing, Rear

132-08350 Needle Rod (A) Asm.

132-08103 Needle Driving Link Washer

EA-9500B01-00 Cable Band

132-09705 Needle Rod Bushing, Upper

132-07808 Needle Rod Bushing Cap Screw

131-10259 Needle Clamp Holder Asm.

131-10200 Needle Clamp Holder

SS-6080720-SP Screw (1/8-44 L=7)

131-10705 Needle Thread Presser Guide A

131-10804 Needle Thread Presser Guide B

131-10903 Needle Thread Presser Spring

131-11000 Needle Thread Presser Plate A

132-08806 Needle Thread Guide

132-08905 Thread Guide, 2-Needle

132-08707 Needle Thread Guide Base

131-11109 Thread Guide, Chain Looper

SM-4040855-SP Screw

SS-4110515-SP Screw (11/64-40 L=5)

131-11208 Needle Thread Take-Up Lever

131-11307 Take-Up Lever, 2-Needle

131-11406 Take-Up Lever, Chain Loop

SS-6090670-TP Screw (9/64-40 L=6)

131-11505 Needle Thread Balance Guide

131-11604 Take-Up Lever Guide, 2-Needle

131-11703 Take-Up Lever Guide, Chain Loop

SM-4040855-SP Screw

132-08459 Once Throuch Oil Pipe Asm.

132-08509 Once Throuch Oil Cover

CQ-2000000-00 Oil Wick

132-44009 Once Throuch Oil Pipe Bushing

132-08608 Once Throuch Oil Felt

131-42609 Pipe Clamp

131-22007 Feed Branch Crank Pin A

131-22304 Feed Branck Crank Pin D

MDC-270B1100 Needle DCX27 #11

131-72754 Thrust Collar Asm.

131-72705 Thrust Collar

SS-8660610-TP Screw (1/4-40 L=6)

SS-8090530-TP Screw (9/64-40 L=5.0)

CQ-2020000-00 Oil Wick

SS-8090530-TP Screw (9/64-40 L=5.0)

CQ-2520000-00 Oil Wick

61

SD-0280401-SL В наличии (на удаленном складе) Винт Тип.MO-3600 (Арт.SD-0280401-SL)

131-75005 Иглодержатель (Арт. 131-75005)

131-75203 Needle Clamp, 2-Needle

122-57002 Chain Looper Needle Clamp, Dea

MDC-270B1100 Needle DCX27 #11

67

SS-8080310-TP Под заказ Винт крепления иглы Тип.MOR-2516кл (Арт.SS-8080310-TP)

132-08004 Needle Driving Link
