6. Feed Mechanism Components (2)

Вернуться к выбору схем

Выбор схемы:

6. Feed Mechanism Components (2)

Как искать запчасти?

1

2

3

4

5

6

7

8

9

10

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

26

27

27

28

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

60

61

62

62

63

64

65

66

67

68

69

70

71

100%

№

Артикул Артикул и наименование

Наименование

132-15157 Feed Rocker Asm.

2

Под заказ винт крепления зуб. рейки SМ 1/8x44 L=6 тип DDL-8700 (Арт. SS-4080620-TP)

3

SS-9111010-SP Под заказ Винт Тип.MO-6900 (Арт.SS-9111010-SP)

132-15306 Rubber Case

132-15405 Rubber Case Gasket

132-15504 Feed Bar Support, Right

132-15603 Feed Bar Support, Left

SS-6090620-TP Screw

121-18303 Dust-Proof Rubber

121-18204 Oil Shield Rubber

132-15702 Rubber Holding Plate

SS-7060310-SP Screw (3/32-56 L=3)

132-15900 Oil Shield Case

132-16007 Oil Shield Case Gasket

SM-4040855-SP Screw

SM-4030455-SP Screw

132-15801 Throat Plate Support

131-22700 Adjusting Shaft Metal

132-16106 Oil Shield Plate

SS-1060610-SP Screw (3/32-56 L=5.5)

132-16205 Feed Cam Oil Shield Plate

SM-6040600-SP Screw (M4 L=6)

132-16304 Oil Shield Plate

131-22809 Differential Feed Graduation

SM-4051255-SP Screw (M5 L=12)

131-21405 Adjusting Stopper

SS-4090515-SP Screw (9/64-40 L=5)

WP-0371016-SD Washer (3.7x8x1)

131-20902 Support Shaft

131-21058 Hrust Collar Asm.

131-21009 Hrust Collar

SS-8660330-SP Screw (1/4-40 L=3.0)

131-20803 Slide Block

131-70204 Rubber Ring

SM-4040855-SP Screw

132-17708 Differential Feed Block

RE-0300000-K0 E-Ring 3

132-13012 Adjusting Screw

131-23302 Differential Feed Screw Spring

131-21306 Adjusting Link

RE-0500000-K0 E-Ring 5

131-21256 Support Shaft Collar Asm.

131-21207 Support Shaft Collar

SS-8110410-TP Screw (11/64-40 L=3.5_

131-21900 Differential Feed Rocker

SS-6661110-SP Screw (1/4-40 L=11)

132-17351 Rocker Shaft Asm.

131-70501 Rubber Ring

131-21603 Adjusting Lever Spring

132-18052 Differential Feed Arm Asm.

51

SS9111050SP Под заказ винт 11/64-40 L=9.5 тип Мо-3304 кл (Арт. SS-9111050-SP)

131-21108 Washer

TA-0800504-R0 Plug (D=8 L=4.5)

132-00902 Feed Mechanism Cover Presser

SS-6080340-SP Screw (1/8-44 L=2.9)

132-18102 Slide Block

132-17401 Differential Feed Hinge Screw

132-17500 Differential Feed Lock Nut

SD-0720271-SP Hinge Screw (D=7.2 H=2.7)

SM-4041055-SP Screw (M4 L=10)

WP-0460556-SD Washer (4.6x7.5x0.5)

WP-0480856-SP Washer (4.8x8.4x0.8)

WP-0621016-SD Washer (6.2x13x1)

131-91606 Main Feed Dog

131-92000 Main Feed Dog

131-92406 Main Feed Dog

131-92802 Differential Feed Dog

131-93206 Differential Feed Dog

131-93602 Differential Feed Dog

131-91309 Auxiliary Feed Dog

131-91408 Auxiliary Feed Dog
