9. Presser Foot Components (1)

Вернуться к выбору схем

Выбор схемы:

9. Presser Foot Components (1)

Как искать запчасти?

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

100%

№

Артикул Артикул и наименование

Наименование

131-15001 Presser Foot Shaft

131-15100 Presser Foot Shaft Bushing

131-15258 Thrust Arm Asm

131-1509 Thrust Arm

SS-6110710-TP Screw (11/64-40 L=6.5)

SS-9151210-TP Screw (15/64-28 L=11.8)

131-16801 Lifting Arm

131-15407 Presser Foot Arm Hinge Shaft

131-15753 Presser Lifting Lever Base Asm

131-15803 Presser Lifting Lever Base

131-15902 Presser Lifting Lever

131-16009 Presser Arm Stopper

131-16108 Presser Foot Lifting Spring

SS-7110510-SP Screw (11/64-40 L=5)

SD-0640241-SP Hinge Screw (D=6.35 H=2.4)

PS-0300142-KH Spring Pin (0.3x14)

SS-6080340-SP Screw (1/8-44 L=2.9)

131-16207 Presser Foot Spring

131-17007 Presser Lifting Lever Screw

131-16306 Presser Lifting Lever Spring

131-16900 Presser Lifting Lever

131-16405 Presser Lifting Hook

131-16504 Lifting Lever Arm Spring

131-16603 Presser Lifting Lever Spring

NM-6060003-SC Nut (M6)

26

NS-6110420-SP Под заказ Гайка 11/64-40 Тип.A-373 (Арт.NS-6110420-SP)

SM-6061200-SP Screw (M6 L=12)

SS-7110840-SP Screw (11/64-40 L=7.8)

SS-7111410-TP Screw (11/64-40 L=14)

SM-8050412-TP Screw (M6 L=4)

400-34897 Presser Adjusting Screw

131-15654 Presser Bar Asm.

122-88700 Presser Regulator Screw Washer

131-17106 Presser Regulator Nut

132-12709 Presser Bar Cover

131-70402 Rubber Ring

131-70402 Rubber Ring

SM-8040402-TP Screw (M4x0.7 L=4)

132-12501 Presser Bar Bushing

SS-6121020-SP Screw (3/16-28 L=9.5)

132-12808 Adjusting Base

132-13012 Adjusting Screw

132-12916 Adjusting Block

131-23302 Adjusting Spring

SS-7150740-SP Screw (15/64-28 L=7)

WP-0460556-SD Washer (4.6x7.5x0.5)

RE-0300000-K0 E-Ring (3)

SS-7161040-SP Screw (1/4-24 L=9.5)
