Вернуться к выбору схем

Выбор схемы:

1.

Как искать запчасти?

1

2

3

4

4

5

6

7

8

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

100%

№

Артикул Артикул и наименование

Наименование

21001 framework

21002 suspended bed

21003 side cover of body

21004 fixing screw of side cover

21005 belt wheel cover

0144016 fixing screw for belt wheel cover

21006 body rear cover

0144008.1 fixing screw for body rear cover

21007 end cover

0174008 screw for end cover

0186016 fixing screw for base

B-005 screw for stand of motor

B-006 washer for stand of motor

B-007 spring washer for stand of motor

0144008.2 fixing screw for lead ring

S-21095 thread compressor stand (no. 21-26)

21095 thread compressor stand

21096 screw stem of thread compressor

4070 disc oscillating rod bracket adjusting screw nut

5190-A thread nipper disc

79-B thread tension spring

TY-83 thread compression nut

0144008.3 fixing screw for thread compressor stand

0046006 fixing bolt for lead lever

21094 thread platform

11145 nut for thread platform

10543 washer for thread platform

S-10513-G sewing depth regulator

6074 fixing bolt for scale disk

10514 stem of scale disk

10516 stem of scale disk adjustment bolt

10515-A spring of scale disk adjustment board

TY-8339 fixing bolt for scale disk adjusting board

21068 scale disk adjustment index plate

21037 skp stitching index plate

10076-A suspended bed linked ring

21085 bolt for suspended bed linked ring

21083 crank of lifter shaft

0216016.1 clamping screw for lifter shaft

21084 lifter shaft

10074 pin of lifter shaft

21082 working table stand

0216016.2 fixing bolt for working table stand

21081 working table

10085 fixing bolt for working table

10082 working table column

0216012 bolt for working table column

21023.1 column ring of working table

0096006.1 fixing bolt for column ring of working table

10083 screw for working table
