Главная Каталог запчастей Запчасти для промышленных швейных машин PROTEX TY-500 PROTEX 2.

2.

Вернуться к выбору схем

Выбор схемы:

2.

Как искать запчасти?

1

2

3

4

5

6

7

8

8

9

10

11

12

12

13

14

15

16

17

18

19

20

20

21

21

22

22

22

23

23

23

23

24

24

25

26

27

27

28

28

29

30

31

32

33

34

35

36

37

37

38

38

39

40

41

42

43

44

45

46

47

48

100%

№

Артикул Артикул и наименование

Наименование

21012 main shaft

21013 main shaft bushing (front)

0096010.1 fixing bolt for mainshaft location sleeve

21014 main shaft bushing (rear)

0096010.2 fixing bolt for mainshaft location sleeve

21015.1 thrust washer of mainshaft

21016.1 mainshaft sleeve

0096006.2 fixing bolt for mainshaft sleeve

21017-G pulley (moss-green)

0096014.1 fixing bolt for belt wheel

21018 eccentric bushing

0096008 fixing bolt sleeve of core wheel shaft

21021 skip stitch gear eccentric shaft

0096010.3 bolt for eccentric shaft

21015.2 washer for eccentric shaft

21020 skip stitch gear (large)

21022 skip stitch gear eccentric shaft fork

21023.2 sleeve of eccentric shaft

0096006.3 fixing bolt for eccentric shaft sleeve

21025 connecting link/rod holding screw

10060.1 tightening screw for connection slice

TY-1627 spring washer of tightening screw for connection slice

17202 connecting link/rod holding screw nut

21026 connecting rod

21027 skip stitch eccentric shaft

21023.3 sleeve of eccentric mainshaft

0096006.4 fixing bolt for sleeve of eccentric mainshaft

0096006.5 fixing bolt for sleeve of eccentric mainshaft

0096010.4 fixing bolt for pull-rod sleeve

21031 connecting link (short)

21032 connecting link holding pin

10060.2 pin spring of connecting slice

0094004.1 fixing bolt for pin of connecting slice

21033 connecting block

0214012.1 fixing bolt for link block

S-21034 ridge forming disc shaft assembly

21036 ridge forming disc shaft collar

0094004.2 fixing bolt for sleeve of ridge forming mainshaft

10517.1 location sleeve of ridge forming mainshaft sleeve

0094006.1 fixing bolt for location sleeve of ridge forming mainshaft sleeve

21069 cylinder bed shaft

0094006.2 fixing bolt for suspended bed

19117 cylinder bed shaft snap ring

21070 cylinder bed shaft spring

21071-A cylinder bed shaft spring pin

21016.2 sleeve of suspended bed shaft

0096006.6 fixing bolt for sleeve of sespended bed shaft

21024 connecting link (long)
